Brand: bobiller
Model No. LHGC-050S52S LHGC-060S62S LHGC-070S72S
Place of Origin: China
Applicable scenes: Cold chain logistics, cold storage, freezer
Evaporation temperature: -15℃-10
Customizable: Customizable
Product price: please consult the website customer service
Product Characteristics
Medium temperature refrigerated liquid injection unit adopts advanced liquid injection cooling technology, the core of which lies in realizing high efficiency refrigeration by precisely controlling the injection of liquid refrigerant. In the refrigeration cycle, the liquid refrigerant is led from the high-pressure section such as condenser or liquid storage, through the precision nozzle and the corresponding valve assembly, and is sprayed into the suction line or compression chamber of the compressor at the correct time and amount. When the load of the refrigeration system increases and the speed of the compressor increases, the discharge temperature will rise, which may lead to the decomposition of the refrigerant and the degradation of the lubricant performance, affecting the efficiency and life of the compressor. The liquid refrigerant injected into the compressor can effectively absorb heat and reduce the discharge temperature, thus protecting the compressor and improving the overall performance of the system.
Efficient refrigeration: Liquid injection cooling technology can quickly absorb heat, reduce the exhaust temperature and improve refrigeration efficiency.
Stable and reliable: through precise control of the refrigerant injection amount, the unit can operate stably under different working conditions and prolong the service life of the equipment.
Energy saving and environmental protection: compared with the traditional refrigeration method, the medium-temperature cold storage liquid injection unit can significantly reduce energy consumption and emission of pollutants.
Widely applicable: the unit is suitable for cold chain logistics, refrigeration and air conditioning, medical equipment and other fields to meet the refrigeration needs of different scenarios.
Product Parameters
Unit Model | LHGC-040S32Q | LHGC-040S32S | LHGC-050S52S | LHGC-060S62S | LHGC-070S72S | |
Evaporation temperature range | -15℃-10℃ | |||||
Refrigerant | R22 | |||||
Voltage | 50Hz,220V | 50Hz,380V | ||||
Compressor type | Scroll compressors | |||||
Fan Parameter | Number | 1 | 1 | 2 | 2 | 2 |
Power(W) | 85W | 85W | 85W | 85W | 85W | |
Fan specification | 0496*150 | 0496*150 | 0496*150 | 0496*150 | 0496*150 | |
Air volume(m³/h)) | 3200 | 3200 | 3600*2 | 3600*2 | 3600*2 | |
Condenser copper tube specifications | 09.52/32U | 09.52/32U | 09.52/48U | 09.52/48U | 09.52/62U | |
Condensing area(m2) | 32 | 40 | 48 | 56 | 65 | |
Shut-off valve specifications | 9.52+15.88 | 9.52+15.88 | 12.7+19.05 | 12.7+19.05 | 12.7+19.05 | |
Throttling configuration | Thermal expansion valve (user-provided) | |||||
Storage temperature 0℃Storage volume(m³) | 40-60 | 40-60 | 60-75 | 75-95 | 95-110 | |
Chiller Model | Self-contained Model | AT401R5 | AT401R5 | AT402R4 | AT402R5 | AT402R6 |
Ordinary model | DL/25 | DL/25 | DL/40 | DL/55 | DL/55 | |
Storage temperature 0 ℃ expansion valve recommended model | 4H | 4H | 5H | 6H | 7H | |
Cooling capacity (W) | evaporating temperature | Test conditions: superheat degree 11.1K; subcooling degree 8.3K; condenser temperature 45℃. | ||||
-15℃ | 5740 | 5740 | 7150 | 8370 | 9410 | |
-10℃ | 6940 | 6940 | 8600 | 10260 | 11390 | |
-5℃ | 8380 | 8380 | 10330 | 12540 | 13800 | |
0℃ | 10130 | 10130 | 12430 | 15340 | 16630 | |
5℃ | 12260 | 12260 | 14950 | 18790 | 19900 | |
Product Size(mm) | 1000*400*870 | 1000*405*870 | 1010*405*1250 | 1010*405*1250 | 1010*405*1250 | |
Package Size(mm) | 1065*425*900 | 1065*415*950 | 1065*415*1290 | 1065*415*1290 | 1115*415*1290 | |
Installation Dimension(LXW)mm | 600*370 | 600*370 | 600*370 | 600*370 | 600*370 | |
