Model | DT-500 | |
Inner liner material | SUS304 | |
Inner cavity thickness(MM) | 1.5 | |
Housing material | ||
Shell thickness(MM) | 0.4 | |
Maximum working pressure(bar) | 8 | |
Hot water tank | Capacity | 330L |
Circular import and export | G1" M | |
Hot and cold water ports | G3/4" M | |
Water return port | G3/4" M | |
Temperature probe port | G3/8" F | |
Anode rod mouth | G3/4" F | |
P/TP valve port | G3/4" F | |
Electric heating port | ||
Electric heating port | ||
Sewage outlet | G3/4" F | |
Coil material | SUS304 | |
Coil thickness(mm) | 0.3 | |
Coil specifications (Bellows) | ||
Coil area(㎡) | 3.3 | |
Buffer Water Tank | Capacity | 120L |
Circular import and export 1 | G1" F | |
Circular import and export 2 | G1" F | |
Temperature probe port | G3/8" F | |
Electric heating port | ||
Electric heating port | ||
Sewage outlet | G3/4" F | |
Exhaust port | G1/2" F | |
Adapted heat pump heat production | Below 18kW | |
Product Size(mm) | φ700*1875 | |
Package Size(mm) | 790*790*1950 | |
Net weight(kg) | 86 | |
Gross weight(kg) | 92 |
