| Section | Specifications & Commercial Strengths | Buyers' Key Benefits |
|---|---|---|
| Product Name | 200L Premium Vertical Buffer Tank / Thermal Storage Vessel | High-capacity buffer tank optimized for global HVAC markets. |
| Primary Function | Increases total hydronic water volume and stores thermal energy. | Prevents heat pump short-cycling and reduces compressor wear. |
| Defrost Support | Provides continuous heat backup during outdoor coil defrost cycles. | Maintains stable indoor temperatures without sudden cold drafts. |
| Tank Material | Premium food-grade SUS304 / SUS316L Stainless Steel (Porcelain Enamel optional). | Ensures excellent corrosion resistance and an extended service lifespan. |
| Insulation Technology | 50mm+ high-density eco-friendly Polyurethane Non-CFC foam layer. | Delivers ultra-low standby heat loss, meeting strict energy efficiency standards. |
| Outer Casing | Heavy-duty pre-painted galvanized steel with a sleek white/black finish. | Weather-resistant, durable, and suitable for high-end mechanical rooms. |
| Hydronic Connection | Multi-port configuration (Female G 1" or G 1-1/4") for flexible piping layout. | Allows for seamless hydraulic separation and easy installation in multi-zone systems. |
| Sensor Integration | Dual pre-installed internal sensor pockets (Φ8mm). | Enables precise water temperature monitoring via the heat pump controller. |
| Auxiliary Heating | Reserved G 1-1/2" port for an optional backup electric heating element. | Offers flexible auxiliary heating options for extreme winter climates. |
| Applications | Air-to-water heat pumps, solar thermal systems, biomass boilers, and chillers. | Versatile integration with underfloor heating, fan coils, and radiators. |
| B2B Global Support | Full OEM/ODM services, custom port layouts, private labeling, and pallet packaging. | Ideal for wholesale importers and heating system manufacturers. |
| Specification Item | Product Details |
|---|---|
| Nominal Capacity | 200 Liters / 52.8 Gallons |
| Installation Type | Vertical Floor-standing |
| Inner Tank Material | Food-grade SUS304 / SUS316L Stainless Steel (Optional Enamel) |
| Outer Shell Material | Pre-painted Galvanized Steel (Corrosion-resistant White Finish) |
| Insulation Material | High-density Polyurethane Non-CFC Foam (Thickness: 50mm) |
| Max. Working Pressure | 0.6 MPa (6 Bar) / Test Pressure: 0.9 MPa (9 Bar) |
| Operating Temperature | -10°C to +95°C |
| Connection Ports | Female G 1" or G 1-1/4" (Customizable Layout) |
| Sensor Pockets | 2 x Φ8mm (For precise temperature monitoring) |
| Heating Element Port | Reserved G 1-1/2" for Auxiliary Electric Heater (Optional) |
